LCD Type Vision Measuring Machine – VMM-2010D/VMM-2010-PC

TRUEMET VMM manual mini desktop two-dimensional machine adopts the desktop design concept and is mainly lightweight and fast. It is
suitable for measuring small workpieces. Because of its compact body and easy docking and use, it can be moved and carried at will. It is
especially suitable for Used in offices and research units.

Features:

TRUEMET VMM fclassic body series manual image measuring instrument comes standard with 2-axis counting and 2D plane measurement functions. It can be optionally equipped with a Z-axis grating ruler (2.5-dimensional) or a contact probe (economical 3-dimensional), paired with professional measurement software, you can measure height and flatness through Z-axis optical image focusing, or measure height, flatness, sphericity, radian, spatial distance, cylinder, cone and other three-dimensional dimensions through a probe. Excellent software and hardware configuration, powerful measurement functions, Super cost-effective, it is your first choice for measurement.

View Catalogue

Get Latest Price

Category: VISION MEASURING MACHINE

Description

Power supply220v± 10% (AC) 50HzPower supply220v± 10% (AC) 50Hz

MODEL	VMM-2010D/VMM-2010-PC
Measuring Size X Y Z （mm）	200×100×200
Glass Plate Size （mm）	228×128
Granite Stage Size (mm)	370×230
Dimension LWH (mm)	577x1250x910 / 577x467x910
Max. loading weight (kg)	20
CCD Camera/Lens	1/2.3” CMOS High resolution HDMI Color Camera / 1/2” GIGE Color Camera 1.3MP
Optical Parameters	0.7~4.5X zoom lens; Working Distance: 90mm Monitor Magnification : 40X-250X View Field: 8 . 1~ 1 .3mm
Light	White LED Ring Light
Control	Manual
linear Encoder Resolution	0.5µm
Accuracy (um)	X-Y≤ (3+L/200) μm, L = measured Length in mm Z Axis ≤ (5+L/50) μm, L = measured Length in mm
Power supply	220v± 10% (AC) 50Hz
Net Weight (kg)	95
Lens position identifier	Double laser pointer
