| MODEL | VMM-3020-T |
| Measuring Size for X Y Z (mm) | 300×200×150 |
| Glass Plate size (mm) | 360×260 |
| Stage Size (mm） | 456×366 |
| Product Size L×W×H （mm） | 780×580×1000 |
| Weight (KG) | 150 |
| Optional | 1. ALS-G:With Linear Encoder to Measure High. 2. ALS-T: With Touch Trigger Probe to Measure High. |
| CCD/ Probe | COMST CCD( 1/3′ ,700TVL) / Optional for Renishaw touch probe |
| Lens | 0 .7-4 .5X Zoom Lens |
| Optical Paremeters | Working Distance ：90mm; Magnification ：26~ 172X; View Field ：8 . 1~ 1 .3mm |
| Light | LED Ring Light |
| Control | Manual/ CNC fro Z-axis/ CNC Fro Z-axis with 3 Values |
| Linear Encoder/Accuracy | 0 .001mm ；Accuracy ：X-Y≤ (3+L/200) μm |
| Power Supply | 220v± 10% / 1 10v± 10% ( AC ) 50Hz |
Video Measuring Machine – VMM-3020-T
Video Measuring Machine – VMM-3020-T
TRUEMET VMM manual mini desktop two-dimensional machine adopts the desktop design concept and is mainly lightweight and fast. It is
suitable for measuring small workpieces. Because of its compact body and easy docking and use, it can be moved and carried at will. It is
especially suitable for Used in offices and research units.
Features:
TRUEMET VMM fclassic body series manual image measuring instrument comes standard with 2-axis counting and 2D plane measurement functions. It can be optionally equipped with a Z-axis grating ruler (2.5-dimensional) or a contact probe (economical 3-dimensional), paired with professional measurement software, you can measure height and flatness through Z-axis optical image focusing, or measure height, flatness, sphericity, radian, spatial distance, cylinder, cone and other three-dimensional dimensions through a probe. Excellent software and hardware configuration, powerful measurement functions, Super cost-effective, it is your first choice for measurement.
