COMPUTERIZED VICKERS HARDNESS TESTER | VHT- SERIES-V2

Features:

1. 1. Auto measurement of the four vertices of the indentation.
   2. Double optical channel (eyepiece & camera port).
   3. Automatically generate Word or Excel Document or PDF report which include each individual curve graph & statistical value.
   4. Test force is automatically display on LCD screen.
   5. DIGITAL EYEPIECE : Equipped with 10x Manual Eyepiece to measure the length of diagonal. The hardness value can be displayed directly on LCD screen by entering the indentation diagonal length.
   6. ILLUMINATION SYSTEM : Halogen illumination unit gives very clear images and can be also used as a simple microscope. Halogen illumination unit enter stand by mode after a certain period of inactivity which gives it a long service life and low power consumption.
   7. LCD SCREEN : 80X25mm LCD Screen can visually display the hardness value, conversion hardness, test force and dwell time.
   8. CAMERA PORT : Machine equipped with dual optical channel, one optical channel for 10X eyepiece and another optical channel is for camera by which machine can be upgraded into computerized model. Both optical channel works simultaneously.
   9. TURRET MECHANISM : Equipped with manual turret mechanism. The position of the indentor and objective lens can be switched manually.
   10. TEST FORCE : Wide range of test force can be selected with external force selection knob. The test force is automatically displayed on the 80X25mm LCD Screen.
   11. EMERGENCY SWITCH : Equipped with emergency stop switch.
