TZM8050T-T9L
TZM8050T-T9L
TZM7050 Series Stereo Zoom Microscope can provide crystal clear sharp images with high resolution and good depth within a broad field of view. Once brought in focus, images remains clear and sharp throughout the whole zoom range. It is widely used in electronic industry, educational demonstration and agricultural research for micro-object observation, inspection and measurement.
| MODEL | TZM8050T-T9L |
| Zoom Range | 0.8x – 50x |
| Zoom Ratio | 1:6.3 |
| Total Magnification | 8-50x(Standard), 4-300x with optional lens |
| Working Distance | 115mm (Standard), 43.5-211mm with optional lens |
| Interpupillary Distance | 52-75mm |
| Diopter Adjustment | +/-5 diopters |
| Binocular Tube | with an inclination of 45 deg for greater ease of observation |
| Binocular Body | Can be rotated a full 360 deg and locked in any position desired |
| Base Size | 205x275x40mm with Φ95mm B/W Plastic & Perspex Plate & Paired Clips |
