TZM6565T-T3
TZM6565T-T3
TZM6565 Series Stereo Zoom Microscope can provide crystal clear sharp images with high resolution and good depth within a broad field of view. Once brought in focus, images remains clear and sharp throughout the whole zoom range. It is widely used in electronic industry, educational demonstration and agricultural research for micro-object observation, inspection and measurement.
| MODEL | TZM6565T-T3 |
| Observation Head | Trinocular head, 45° tilt, 360° rotation, pupil distance 54—76mm; bilateral diopter adjustment ±5 diopters |
| Adjustable eyepiece | Standard configuration: WF10X22, High angle wide angle eyepiece, provide convenience for observers wearing glasses |
| Optional eyepiece | WF20X12mm |
| Objective | 0.65X—6.5X Zoom Range, objective magnification ratio 1:10, Ensure image alignment |
| Auxiliary Lens | 0.3X, 0.5X, 0.7X, 1X, 1.5X, 2X optional |
| Magnification | Standard 6.5X—65X, Optional and auxiliary lenses can be extended to 2X—260X, Continuous doubling |
| Working Distance | 110mm |
| Focus arm | Inner diameter 76mm, column hole diameter 32mm |
| Base | T3 column type large plate base (Standard), Other base can be selected |
| Outward Size | 320mm(W) x 260mm(D) x 16mm(H) |
| Photographic eyepiece | 0.5XCTV |
