| MODEL | TRH-150DM |
| Preliminary test force | 98.07 N (10kgf) |
| Total Test force | 588.4 N, 980.7 N,1471 N (60,100,150 kgf) |
| Display | LCD Display |
| Scales Display | HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK, HRL, HRM, HRP, HRR, HRS, HRV |
| Minor load setting | By bar graph indicator (Manual setting) |
| Load Control | Automatic (Loading, Dwell, Unloading) |
| Dwell Time | 0-60sec |
| Least Count | 0.1 HR |
| Data Output | Mini USB Port |
| Memory | 500 Readings |
| Max. test height | 180mm |
| Depth of throat | 135 mm (from the centre to of indenter) |
| Power Supply | Built in rechargeable battery (Charger AC 240 volts; DC 5V, 1A) |
| Dimension (H x W x L) | 630x238x466mm |
| Net Weight (Approx) | 65 kg |
Motorized Rockwell Hardness Tester | TRH-150DM
Motorized Rockwell Hardness Tester | TRH-150DM
Features:
-
- Motorized Digital Rockwell Hardness Tester
- Touch Screen panel for Dwell time selection and test cycle start.
- Automatic testing (Loading, Dwell, Unloading) after applying the preliminary test force by hand.
- Minor load setting by LCD bar graph
- Tolerance measurement with alarm indication.
- Easy to read, large Size 320 x 240 TFT LCD display.
- Measurement value can be sent to PC through USB cable (optional).
- Memory of 500 measurement values for browsing and output.
- Set measurement times (2-9) to have average value and difference to max. and min. value.
- Hardness conversion facility available as per ISO-18265 and ASTM-E140 in different scales such as Brinell, Vickers, Knoop, Leeb, Rockwell & Rockwell Superficial.
- Automatic power off.
