| MODEL | TEST FORCE (KGF) | MAGNIFICATION |
| THT-10A | 0.1, 0.2, 0.3, 0.5,1, 2, 2.5, 3, 5, 10 | 400X (FOR MEASUREMENT) & 100X (FOR OBSERVATION) |
| THT-30A | 0.2, 0.3, 0.5,1, 2, 2.5, 3, 5, 10, 20, 30 | 200X (FOR MEASUREMENT) & 100X (FOR OBSERVATION) |
| THT-50A | 0.3, 0.5,1, 2, 2.5, 3, 5, 10, 20, 30, 50 | 200X (FOR MEASUREMENT) & 100X (FOR OBSERVATION) |
| THT-100A | 1, 2, 2.5, 3, 5, 10, 20, 30, 50, 100 | 200X (FOR MEASUREMENT) & 50X (FOR OBSERVATION) |
THT-A Series-V4 | Computer Controlled Load Cell Based Vickers Hardness Tester
THT-A Series-V4 | Computer Controlled Load Cell Based Vickers Hardness Tester
Features:
-
- MANUAL EYEPIECE : Equipped with 10x Manual Eyepiece to measure the length of diagonal. The hardness value can be displayed directly on LCD screen by entering the indentation diagonal length.
- ILLUMINATION SYSTEM : Halogen illumination unit gives very clear images and can be also used as a simple microscope. Halogen illumination unit enter stand by mode after a certain period of inactivity which gives it a long service life and low power consumption.
- LCD SCREEN : 80X25mm LCD Screen can visually display the hardness value, conversion hardness, test force and dwell time.
- CAMERA PORT : Machine equipped with dual optical channel. 5 MP USB Camera is connected to one of the dual optical channels, other optical channel is for 10X eyepiece. Both optical channel works simultaneously.
- TEST FORCE : All the test force is applied by load cell. The high quality load sensing system can do a wide-range of vickers test by one load cell.
- AUTO TURRET MECHANISM : Equipped with auto turret mechanism. Auto turret perform a series of operation and measuring lens automatically comes back to central position after making indentation. The position of the indenter and the objective lens can be automatically switched using keypad.
- EMERGENCY SWITCH : Equipped with emergency stop switch.
| MODEL | THT-A Series-V4 |
| Turret Movement | Automatic |
| Measuring Eyepiece | 10X Manual Eyepiece |
| Display | 80X25mm LCD screen |
| Hardness Conversion Scale | HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HBW, HK (as per ASTM & ISO standard) |
| Hardness Range | 1-4500 HV |
| Optical Channel | Dual Light Channel (Eyepiece and Camera Channel) |
| Dwell Time | 1~99 sec |
| Loading Control | Automatic (Loading, Dwell, Unloading) |
| Max height of specimens (approx) | 165mm |
| Max depth of specimens (approx) | 130mm |
| Light Source | Halogen Bulb (with adjustable intensity) |
| Data Output | Built in RS-232 interface |
| Carried Standard | ASTM-E384 & E92, ISO 6507, IS 1501 |
| Overall Dimension (approx) | 585X200X630 mm (L X W X H) |
| Net weight (approx) | 42Kg |
| Power Supply | AC220V±5% 50-60Hz |
| Standard Accessories | Vickers Indentor 1 No. 10X Digital Eyepiece 1 No. Objective 10X 1 No. Objective 40X or 20X 1 No. Flat testing table (50mm diameter) 1 No. V testing table (60mm diameter) 1 No. Hardness Test Block 2 Nos. Allen Keys 1 No. Leveling Adjusting Screw 4 Nos. Power Cord 1 No. Screw Driver 1 No. Dust Cover 1 No. Leveling Bubble 1 No. Accessory case 1 No. Instruction Manual 1 No. |
| VIDAS 4.0 Kit | TRUEMET VIDAS-Vickers Impression Diagonal Analysis System, 5 MP USB Camera & Camera Adaptor. |
| Optional Accessories | Knoop Indentor, Knoop Hardness Block, Manual XY Table, Digital XY table, SPC Cable. |
