TZM7050T-R3L
TZM7050T-R3L
TZM7050 Series Stereo Zoom Microscope can provide crystal clear sharp images with high resolution and good depth within a broad field of view. Once brought in focus, images remains clear and sharp throughout the whole zoom range. It is widely used in electronic industry, educational demonstration and agricultural research for micro-object observation, inspection and measurement.
| MODEL | TZM7050T-R3L |
| Zoom Range | 0.7x-5.0x |
| Zoom Ratio | 1:6.4 |
| Total Magnification | 7-50x(Standard), 3.5-270x with optional lens |
| Working Distance | 100mm(Standard), 30-287mm with optional lens |
| Interpupillary Distance | 54-76mm |
| Diopter Adjustment | +/-5 diopters |
| Binocular Tube | An inclination of 45° for greater ease of observation |
| Binocular Body | Can be rotated a full 360° and locked in any position desired |
| Trinocular Body | 0%/100%, 50%/50%, 20%/80%, with a vertical phototube |
