Computer Controlled Automatic Touch Screen Micro Vickers Hardness Tester | HT-1000AT-V5
Computer Controlled Automatic Touch Screen Micro Vickers Hardness Tester | HT-1000AT-V5
Semi Automatic Micro Vickers Hardness Tester is a state-of-the-art instrument designed for accurate hardness measurements. Perfect for quality control, material testing, and research, this device combines ease of use with reliable performance.
Features:
-
- Motorized XY-stage, controlled by built-in stepping motor has variety of control modes accessed by mouse click control.
- Automatically scan along the edge of the sample and generate test point by defined pattern.
- System provide more than 18 different pattern to meet customer requirements.
- Software controlled hardness tester to switch between objective lens and indenter without manual control of hardness tester.
- Various Data Output : Automatic hardness measurement, hardness curve graph, hardness conversion, statistical calculation, working data saving & retrieval and hardness report.
| MODEL | HT-1000AT-V5 |
| Turret Movement | Automatic |
| Measuring Eyepiece | 10X Manual Eyepiece |
| Display | 7 inch LCD touch screen |
| Testing Force | 10gf (0.098N) 25gf (0.245N) 50gf (0.49N) 100gf (0.98N) 200gf (1.96N) 300gf (2.94N) 500gf (4.9N) 1000gf (9.8N) |
| Test Force Selection | External Force Selection Knob, The Test Force is Automatically Display on the 7inch LCD Touch Display as well as in PC |
| Hardness Scale | HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1 |
| Hardness Conversion Scale | HRA, HRB, HRC, HRD, HRF, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HBW, HBS, HK, HS (as per ASTM & ISO standard) |
| Hardness Range | 1~4500 HV |
| Magnification | 100 X (For observation), 400 X (For Measurement) |
| Optical Channel | Dual Light Channel (Eyepiece and Camera Channel) |
| Dwell Time | 5~60 sec |
| Loading Control | Automatic (Loading, Dwell, Unloading) |
| XY Testing Table | Motorized XY Table Size (mm) : 100X100 Max., Travel range : 25X25mm, Resolution 0.001mm |
| Max height of specimens (approx) | 85mm |
| Max depth of specimens (approx) | 110mm |
| Light Source | Halogen Bulb (with adjustable intensity) |
| Data Output | Built in RS-232 interface |
| Complying Standard | ASTM-E384 & E92, ISO 6507, IS 1501 |
| Overall Dimension (approx) | 530X200X530 mm (L X W X H) |
| Net weight (approx) | 35Kg |
| Power Supply | AC220V±5% 50-60Hz |
| Standard Accessories | Vickers Indentor 1 No. 10X Manual Eyepiece 1 No. Objective 10X 1 No. Objective 40X 1 No. Standard 2 jaw vise (Jaw opening : 38mm) 1 No. Thin Specimen Holder (Thickness Max : 6mm) 1 No. Slender specimen holder (vertical) (Diameter : 0.4-4mm) 1 No. Hardness Test Block (HV 0.2) 1 No. Hardness Test Block (HV 1) 1 No. Allen Keys 1 No. Leveling Adjusting Screw 4 Nos. Power Cord 1 No. Screw Driver 1 No. Dust Cover 1 No. Leveling Bubble 1 No. Accessory Box 1 No. Instruction Manual 1 No. |
| VIDAS 5.0 Kit | TRUEMET VIDAS Vickers Impression Diagonal Analysis Software, 5 MP USB camera, camera adopter, XY motorized table, controller box, hardware lock, software pendrive |
| Optional Accessories | VIDAS 6.0 (Motorized Z-AXIS), Knoop Indentor, Knoop Hardness Block. |
