| MODEL | TLRH-xCurve | TLRSH-xCurve |
| Initial Test Force (N) | 98.07 N (10 KGF) for Rockwell | 29.42 N (3 KGF) for Superficial 98.07 N (10 KGF) for Rockwell |
| Main Test Force (N) | 588.4N (60kgf), 980.7N (100kgf), 1471N (150kgf) | 147.1N (15kgf), 294.2N (30kgf), 441.3N (45kgf),
588.4N (60kgf), 980.7N (100kgf), 1471N (150kgf) |
| Display | 8 inch Touch Screen | |
| LCD touch screen display | Hardness value, Hardness scale, Force time curve, Depth time curve, Total test force, Permanent Indentation depth, Holding time, Upper and lower limit setting value, Last five hardness values, Minimum, maximum and their average, Date, Time, Day. | |
| Max Test Height | 260mm | |
| Depth of Throat | 165mm | |
| Dwell time | 1~99s | |
| Data output | Built-in printer, RS232 interface | |
| Accuracy | ASTM E18, ISO 6508 – 2, IS 1586 (Part 2) | |
| Allow sample height/Throat | 170mm/165mm | |
| Dimension (mm) | 490X165X740 (length x width x height) approx. | |
| Weight | 70 kg approx | |
| Power | 220V AC, 50Hz | |
TLRH-xCurve / TLRSH-xCurve | Load Cell Based Touch Screen Rockwell Hardness Tester
TLRH-xCurve / TLRSH-xCurve | Load Cell Based Touch Screen Rockwell Hardness Tester
Features:
-
- Load cell based.
- Touch screen operation.
- Real time display of Force-Time Curve.
- Resolution : 0.01 HR.
- Testing Cycle starts just after touching the specimen with indenter (no need to apply initial test force).
- GO/NG tolerance judgement.
- Hardness scale conversion HR, HB, HV.
- Built-in thermal printer.
- Load/Scale selection through touch panel.
- Built-in flexible illumination light source to focus light on test area.
