| MODEL | PHT-IM |
| Measuring range & Scale | (170-960) HLD |
| Measuring direction | 360° |
| Accuracy | ±6HLD referred To Leeb Hardness Test Block of 760±30 HLD |
| Power Supply | Dry cell batteries (1.5 VDC X 2Nos.) Size -AA, Type -R6. |
| Communication interface | USB |
| Dimension | 125X70X26mm (main unit) |
| Weight | Approx 350gm (Display Unit with battery) |
| Display | LCD, 52X30 matrix LCD |
Portable Hardness Tester – PHT-IM
Portable Hardness Tester – PHT-IM
Features:
-
- Large LCD Display (30X52 dot matrix) showing hardness value, direction of impact device, hardness scale, material, test time for average and battery icon.
- Direct display of hardness in HV, HB, HRC, HRB, HRA and HS scales.
- 7 types of impact devices can be attached for special application and need not to be recalibrated when changing them.
- The machine identify the type of impact device automatically.
- Upto 600 groups (impact times:32 ~1) of data can be stored in internal memory of the machine.
- Upper and lower limit of hardness can be preset. when the tested value exceeds the limits, alarm buzz automatically.
- Back light on/off facility is given by pressing key to make machine converient for use in poor light.
- User calibration function.
- By Using software, data can be transfered and saved in pc for future use.
