| MODEL |
HBE-3000L |
| Display |
LCD |
| Brinell Scale |
HBW2.5/62.5 HBW2.5/187.5 HBW5/62.5 HBW5/125 HBW5/250 HBW5/750 HBW10/100 HBW10/250 HBW10/500 HBW10/1000 HBW10/1500 HBW10/3000 |
| Test force |
62.5kgf(612.9N), 100kgf(980.7N), 125kgf(1226N), 187.5kgf(1839N), 250kgf(2452N), 500kgf(4903N), 750kgf(7355N), 1000kgf(8907N), 1500kgf(14710N), 3000kgf(29420N) |
| Load control |
Automatic (loading/dwell/unloading) |
| Maximum test height |
220mm |
| Depth of throat |
130mm |
| Minimum measuring unit |
0.005mm |
| Dwell time |
1-99 sec |
| Measuring range |
8-650HBW |
| Hardness value read |
20X |
| Executive standard |
EN, ISO 6507, EN ISO 6506, ASTM E-384, ASTM E-10-08, ASTM E-384 |
| Indenter-upper wall distance |
55mm (can increase the pressure from the indenter to the upper wall by customizing the indenter) |
| Hardness reading |
After the indentation is measured through the Brinell Microscope, the length of the indentation is directly input by the button to obtain the hardness value. |
| Data output |
Built-in printer, print content: test conditions, number of measurements, average, maximum, minimum, maximum error, etc. |
| Power requirements |
AC200V±10%, 50Hz |
| Dimensions (mm) |
520x210x745mm |
| Weight |
120kg |
