HT-1000AT-V4 | Computer Controlled Touch Screen Micro Vickers Hardness Tester

Features:

1. 1. MANUAL EYEPIECE : Equipped with 10x Manual Eyepiece to measure the length of diagonal. The hardness value can be displayed directly on the screen by entering the indentation diagonal length.
   2. ILLUMINATION SYSTEM : Halogen illumination unit with adjustable intensity gives very clear images and can be also used as a simple microscope. Halogen illumination unit enter stand by mode after a certain period of inactivity which gives it a long service life and low power consumption.
   3. DATA OUTPUT : Equipped with built-in thermal printer to take the print out the hardness result. USB port is also available to get the data in pendrive. RS232 port is available to connect the machine with PC.
   4. CAMERA PORT : Machine equipped with dual optical channel. 5 MP USB Camera is connected to one of the dual optical channels, other optical channel is for 10X eyepiece. Both optical channel works simultaneously.
   5. TEST FORCE : Wide range of test force (10gm to 1000gm) can be selected with external force selection knob. The test force is automatically displayed on the 7 inch LCD touch display as well as in PC.
   6. AUTO TURRET MECHANISM : Auto turret perform a series of operation automatically. Measuring lens automatically comes back to central position after making indentation. The position of the indenter and the objective lens can be automatically switched from PC as well as using touch panel.
   7. LCD TOUCH SCREEN PANEL : 7 Inch LCD touch screen can visually display the hardness value, hardness conversion (4 conversion scales can be displayed at the same time), test force, dwell time, statistical data, upper & lower limit and brightness of optical system.
   8. Z-AXIS LIFTING SYSTEM : Side-Ways lifting system makes the z-axis movement more stable and accurate.
   9. EMERGENCY SWITCH : Equipped with emergency stop switch.
