| MODEL | HT-1000ADT-XYZ |
| Turret Movement | Automatic |
| Display | 7 inch LCD touch screen |
| Testing Force | 10gm (0.098N) 25gm (0.245N) 50gm (0.49N) 100gm (0.98N) 200gm (1.96N) 300gm (2.94N) 500gm (4.9N) 1000gm (9.8N) |
| Test Force Selection | External Force Selection Knobe, The Test Force is Automatically Display on the 7inch LCD Touch Display |
| Hardness Scale | HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1 |
| Hardness Conversion Scale | HRA, HRB, HRC, HRD, HRF, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HBW, HBS, HK, HS |
| Hardness Range | 1-4500 HV |
| Magnification | 100X (For observation), 400X (For Measurement) |
| Dwell Time | 5~60 sec |
| Loading Control | Automatic (Loading, Dwell, Unloading) |
| X-Y Testing Table | Motorized XY Table : Size (mm) : 100X100 Max, Travel range : 25X25mm, Resolution : 0.01mm |
| Max height of specimen | 85mm |
| Max depth of specimens | 110mm |
| Light Source | Halogen Bulb (with adjustable intensity) |
| Data Output | Built in RS-232 interface |
| Complying Standard | ASTM-E384 & E92, ISO 6507, IS 1501 |
| Overall Dimension (Approx) | 530X200X530 mm (L X W X H) |
| Net weight(Approx) | 35Kg |
| Power Supply | AC220V±5% 50-60Hz |
| Standard Accessories | Vickers Indentor 1 No. Objective 10X 1 No. Objective 40X 1 No. Motorized X-Y Testing Table 1 No. Standard 2 jaw vise(Jaw opening : 38mm) 1 No. Thin Specimen Holder (Thikness Max : 6mm) 1 No. Slender specimen holder (Vertical)(Diameter : 0.4-4mm) 1 No. Hardness Test Block(HV 0.2) 1 Nos. Hardness Test Block(HV 1) 1 Nos. Allen Keys 1 No. Leveling Adjusting Screw 4 Nos. Power Cord 1 No. Screw Driver 1 No. Dust Cover 1 No. Leveling Bubble 1 No. Accessory Box 1 No. Instruction Mannual 1 No. VIDAS 6.0 (5 MP camera, XY motorized table, controller box, hardware lock, software pendrive) 1 set. |
Fully Automatic Touch Screen Digital Micro Vickers Hardness Tester – HT-1000ADT-XYZ
Fully Automatic Touch Screen Digital Micro Vickers Hardness Tester – HT-1000ADT-XYZ
Features:
-
- Motorized XY-stage controlled by built-in stepping motor has a variety of control modes through mouse click control, high positioning accuracy, good repeatability, fast moving speed, and high work efficiency.
- Automatically scan along the edge of the sample.
- Multifunction 7-inch touch screen panel.
- Double optical channel (eyepiece & camera port).
- Automatic effective care depth determination.
