Double Disc Metallographic Sample Grinding and Polishing Machine (TPM-2VD)
Double Disc Metallographic Sample Grinding and Polishing Machine (TPM-2VD)
Features:
- The shell is made of high-end ABS, which has a novel appearance and high-end atmosphere.
- The faucet adopts all-copper chrome plating process, which has good corrosion resistance.
- Stepless speed regulation, convenient and quick to meet various needs.
- The double-disc design makes sample preparation more efficient.
- The grinding and polishing plate can be rotated clockwise or counterclockwise to meet different needs
Rotation direction of grinding & polishing discForward and reverseRotation direction of grinding & polishing discForward and reverseRotation direction of grinding & polishing discForward and reverseRotation direction of grinding & polishing discForward and reverse
Rotation speed of grinding discEight gear fixed speedRotation speed of grinding discEight gear fixed speed
Rotation speed of grinding discEight gear fixed speedRotation speed of grinding discEight gear fixed speedRotation speed of grinding discEight gear fixed speed
| MODEL | TMP-2VD |
| Diameter of Grinding Disc | Standard φ203mm (other specifications customized) |
| Rotating Speed of Grinding Disc | 50-1000r/min (stepless speed regulation) |
| Rotation direction of grinding & polishing disc | Forward and reverse |
| Power Supply | Voltage: 220V Frequency: 50HZ |
| Motor | 0.55KW |
| Appearance size | 730×765×320mm |
| Weight | 42Kg |
