Computerized Brinell Hardness Tester | HB-3000 PC
Computerized Brinell Hardness Tester | HB-3000 PC
Features:
- Fully computerized Brinell Hardness Tester.
- Hydraulic Load and Unload cycle.
- Test force ranging from 250 to 3000 in stages of 250 kgf.
- Manual turret control.
- Automatically measure the Indentation with a single click and given the Brinell Hardness Value.
- System automatically generates a Microsoft Word or Excel Document or PDF file which contains the measurement data, statistical information, measurement image and the hardness curve graph.
| MODEL | HB-3000 PC |
| Test Loads (kgf) | 250 to 3000 in stages of 250 kgf |
| Maximum Test Height (mm) | 380 |
| Scale Least Count (mm) | 0.001 |
| Throat Depth (mm) | 200 |
| Weight (Approx) (mm) | 450 |
| Power Supply (V/Cy/Ph) | 415/50/3 |
| Measurement Range (mm) | 1-6 |
